Technovision TM18

TecMP3 Image

   The Technovision® TM18 is an industrial single channel (mono) WAV playback device, capable of either continuous audio or interactive playback through user-selectable tracks. The TM18 is designed for commercial voice quality playback applications, allowing for direct access to individual (or multiple scripted) tracks of audio through various pushbuttons. The TM18 can also be triggered by motion sensors, computers, or RS232 multimedia controllers like the KPC2 , TC1 or AC1 to play back audio files as well as triggering an external relay.

Physical Specifications
Power Requirements:
  Input: 12 to 32 VDC.
  120VAC/60 Hz to 12V DC adapter included.
  Optional 24V DC power adapter available.
  Idle Current: 60ma @ 12Vdc.
  Active Current: 500ma @ 12Vdc (with 8 ohm speakers).
Net Weight:
  1 lb.
Operating Temperature/Humidity:
  -30C to 85C / non-condensing.
  SD/SDHC cards may have different ratings.
Dimensions (WxDxH)
  4.6" x 3.25" x 1.25"

Download
TM18 Quick Reference Guide
........more manuals
Related Products
   JCCSPK center channel speakers
SP22 speakers
Motion Sensors
Pushbuttons
TM21 single button MP3 player
TECMP3 Stereo industrial player
KPC-2 Controller
AC-1 Controller
Related Products

Standard Features
  • ALL DIGITAL SD/SDHC player.
  • BUILT IN AMPLIFIER
  • Mono speaker output on screw terminals.
  • Up to 15W into 8 Ohm (with 32Vdc P/S).
  • Plays uncompressed MONO 8-bit PCM (Windows WAV).
  • 500+ hours using a 32GB SDHC (FAT32) card (optional).
  • RS232 serial port (DB9F).
  • External volume control knob for speaker and LINE output.
  • MONO LINE output on a 1/8" (3.5 mm) mono jack.
  • Terminal connector for access to 8 tracks.
  • Access to 8x99 tracks in sequential mode.
  • RoHs compliant
  • Mounting tabs on the side.
  • Terminal connector for power.
Hardware Options:
PC2-B4 Four Button harness
JCCSPK center channel speaker
SP2.2 Bookshelf speakers
1GB to 16GB SDHC cards
